FocalCheck™ 荧光显微镜测试玻片 #1,用于对齐、强度&定标
FocalCheck™ 荧光显微镜测试玻片 #1,用于对齐、强度&定标
Invitrogen™

FocalCheck™ 荧光显微镜测试玻片 #1,用于对齐、强度&定标

FocalCheck™ 荧光显微镜测试玻片 #1 专门设计用于定标荧光显微镜系统并评估系统和滤光片性能。玻片 A 行包含 10 个包被有 FocalCheck™了解更多信息
Have Questions?
货号数量
F36909各 1 个
货号 F36909
价格(CNY)
6,890.00
Each
添加至购物车
数量:
各 1 个
价格(CNY)
6,890.00
Each
添加至购物车
FocalCheck™ 荧光显微镜测试玻片 #1 专门设计用于定标荧光显微镜系统并评估系统和滤光片性能。玻片 A 行包含 10 个包被有 FocalCheck™ 环状染色微球的样本区域,微球粒径为 0.5-15 μm,可提供仪器失调或其他像差的视觉显示;B 行包含一系列荧光强度介于 0.667-100% 之间的微球。

请参阅我公司完整的显微镜定标试剂组合 ›

仅供科研使用。不可用于诊断程序。
规格
校准类型共聚焦显微镜校准、荧光显微镜校准
产品规格悬浮微珠
产品线FocalCheck
数量各 1 个
运输条件室温
颜色多种颜色
产品类型荧光显微镜检测玻片
Unit SizeEach
内容与储存
在室温下储存。

常见问题解答 (FAQ)

What are the excitation/emission wavelengths for the beads in FocalCheck Fluorescence Microscope Test Slide #1, for alignment, intensity, & calibration (Cat. No. F36909)?

The spectral characteristics are as follows:

  • A1: 505/515, 560/580, 660/680
  • A2: 365/430 (core), 505/515 (ring)
  • A3-5: 365/430, 505/515, 580/600, 660/680
  • B1-5: 505/515


Find additional tips, troubleshooting help, and resources within our Cell Imaging Support Center.

What type of coverslips are used for the FocalCheck Fluorescence Microscope Test Slide #1 (Cat. No. F36909)?

The coverslips are made of borosilicate glass (#1.5; ~0.17 mm thickness).

Find additional tips, troubleshooting help, and resources within our Cell Analysis Support Center.

Are the microspheres from FocalCheck Fluorescence Microscope Test Slide #1 (Cat. No. F36909) in one plane?

No. Most of the 15 µm beads (Position A1 on the slide) would be within the narrowest focal plane, but they are not guaranteed to all be within the same plane.

Find additional tips, troubleshooting help, and resources within our Cell Analysis Support Center.

引用和文献 (7)

引用和文献
Abstract
Human mitochondrial RNA decay mediated by PNPase-hSuv3 complex takes place in distinct foci.
Authors:Borowski LS, Dziembowski A, Hejnowicz MS, Stepien PP, Szczesny RJ,
Journal:Nucleic Acids Res
PubMed ID:23221631
RNA decay is usually mediated by protein complexes and can occur in specific foci such as P-bodies in the cytoplasm of eukaryotes. In human mitochondria nothing is known about the spatial organization of the RNA decay machinery, and the ribonuclease responsible for RNA degradation has not been identified. We demonstrate ... More
Simple, rapid zebrafish larva bioassay for assessing the potential of chemical pollutants and drugs to disrupt thyroid gland function.
Authors:Raldúa D, Babin PJ,
Journal:Environ Sci Technol
PubMed ID:19764258
Thyroid function may be altered by a very large number of chemicals routinely found in the environment Research evaluating potential thyroid disruption is ongoing, but there are thousands of synthetic and naturally occurring drugs and chemicals to be considered. European and United States policies call for the development of simple ... More
Fluorescent coherent diffractive imaging with accelerating light sheets.
Authors:Field JJ, Squier JA, Bartels RA
Journal:Opt Express
PubMed ID:31052833
'Fluorescence microscopy is a powerful method for producing high fidelity images with high spatial resolution, particularly in the biological sciences. We recently introduced coherent holographic image reconstruction by phase transfer (CHIRPT), a single-pixel imaging method that significantly improves the depth of field in fluorescence microscopy and enables holographic refocusing of ... More
IL-1ß-induced and p38
Authors:Kulawik A, Engesser R, Ehlting C, Raue A, Albrecht U, Hahn B, Lehmann WD, Gaestel M, Klingmüller U, Häussinger D, Timmer J, Bode JG
Journal:J Biol Chem
PubMed ID:28223354
The IL-1ß induced activation of the p38
Enhanced Image Sensor Module for Head-Mounted Microscopes<sup/>.
Authors:Juneau J, Duret G, Robinson J, Kemere C
Journal:Conf Proc IEEE Eng Med Biol Soc
PubMed ID:30440519
Several research groups have developed head-mounted fluorescence microscopes as a modality for recording neural activity in freely behaving mice. The current designs have shown exciting results from in vivo imaging of the bright dynamics of genetically encoded calcium indicators (GECI). However, despite their potential, head-mounted microscopes are not in use ... More
